GNSS GIS Receiver Waterproof Handheld GPS

                            GNSS GIS Receiver Waterproof Handheld GPS

         With Windows Mobile 6.5 you may upload necessary utilities or software on your Qmini M ,to suit your next job .

        You can collect GIS/GPS points and maps via the GIS application of your choice , either a third-party software such as ESRI ,ARCPAD or the proprietary Hi-Target application.

The picture of Handheld GPS

What's the advantage of our Handheld GPS?

What is the Technical Paremeters of our Handheld GPS?

SYSTEM CONFIGURATION

Operating system: Windows Mobile 6.5
Processor: 806 MHz
RAM: 256 MB RAM
Flash memory: 8 GB
Display: 3.7 inch LED, 640×480 resolution

GPS FEATURES

GPS L1&BDS B1
Built-in high sensitivity anti-interference GPS antenna
Update rate: 1 fix/s (user configurable)
Update rate: 1 Hz (configurable w/ future FW 2 Hz Max)
Time to first fix (TTFF): 35 seconds (typical)

POSITION ACCURACY

Single Point Positioning: 5 m

APPLICATION FUNCTIONS

5 million pixel camera with LED
Built-in speaker

COMMUNICATION INTERFACE

Bluetooth
Mini USB
WIFI:802.11b/g
MicroSD card slot, support up to 32 GB
Built-in 3G module

POWER SUPPLY

3.7V, 3100 mAh lithium battery, up to 8 hours continuous work, online charging

PHYSICAL PROPERTIES

10 keys, with the four arrow keys
Size: 152 mm x 82 mm x 32 mm
Weight: 315 g (with battery)
Operating temperature: -20℃~+70℃
Storage temperature: -30℃~+80℃
Dustproof / waterproof: IP65
Anti-shock: 1.5 m free fall

How does the GIS information management system run through our product?

What is our related products?

GNSS GIS Receiver Waterproof Handheld GPS Images
